Round shape LED screen or circle Logo led video display is a unique design of Visual power.
Below is a 1m diameter outdoor P4 LED circular display which is edgeless.
It is mainly used to play some simple logos, image and short video to attract customers into the store.
| Quantity: | |
|---|---|
Product Description
Adhaiwell is Manufacturer of Circle Logo LED Video Display in China
Round shape LED screen or circle Logo led video display is a unique design of Visual power. Below is a 1m diameter outdoor P4 LED circular display which is edgeless. It is mainly used to play some simple logos , image and short video to attract customers into the store.
High Definition Outdoor Circular SMD P4 LED Video Advertising Display
Quick Installation
Ultra-thin design, intelligent mounting bracket for quick and easy installation.
Double Sided
Make your shops more attractive from long distance. Double-sided design can get people's attention from different directions.
Easy operation
Plug and play, friendly use software, USB/ WiFi to update the programs easily.
Features & Benefits
• Waterproof, eye-catching
• Low power consumption
• Easy to assemble and maintain
• It is popularly used in banks, shops, bars, streets, cafes, etc.
Round Logo LED Video Display Parameters
Item | Technical Parameters |
Pixel composition | 1R1G1BLED （SMD1921） |
Pixel pitch | 4.68mm |
Module size | 300mm*300mm |
Module resolution | 64x64 |
LED chip | Sanan |
LED package form | Kinglight Package SMD Three-in-One |
Display density | 4096 dots/side |
Maximum white balance brightness | ≥4500 cd/㎡ |
Gray level | Red, green, and blue ≥ 256 levels, |
Display color | ≥16.7M species, up to 281 trillion species |
Out of control points | ≤1/10000 |
Best view distance | ≥4.6M |
Viewing angle | Level: ≥120°Vertical≥120° |
Device driver | 1/8 Scan （MBI5124） |
Brightness adjust method | 256 grads software adjustments, 16 grads automatic adjustments |
Change frame frequency | ≥60Hz |
Refresh rate | ≥1920Hz |
Control method | asynchronous |
Waterproof grades and materials | IP65 |
Longevity | ≥100,000 hours. |
Operating Voltage | AC110- 220V±15%，50Hz±2 Hz |
Environmental temperature and humidity | Temperature：-20℃～+60℃，Humidity：10%-95% |
Power consumption (maximum/average) | 300W/Pcs |
Smoothness | Adjacent image between ≤ 0.5mm; module splicing gap ≤ 0.5mm |
Maintenance method | Front-maintenance |
Screen weight | ≤16Kg/ Pcs |
Uniformity | Pixel light intensity, uniform module, single point correction per pixel |
Switching power supply | 3.8V/60A |
Control System | Wired Nova star TB1, WIFI |
Circular Logo LED Display is the latest round store led video signboard, it's a good solution to replace traditional lighting box and makes your brand more remarkable and valuable.
